NETWORK

Technology

GSM / HSPA / LTE

LAUNCH

Announced

2017, September 12

Status

Available. Released 2017, November 03

BODY

Dimensions

143.6 x 70.9 x 7.7 mm (5.65 x 2.79 x 0.30 in)

Weight

174 g (6.14 oz)

Build

Glass front (Gorilla Glass), glass back (Gorilla Glass), stainless steel frame

SIM

Nano-SIM

IP67 dust/water resistant (up to 1m for 30 mins)
Apple Pay (Visa, MasterCard, AMEX certified)

DISPLAY

Type

Super Retina OLED capacitive touchscreen, 16M colors

Size

5.8 inches, 84.4 cm² (~82.9% screen-to-body ratio)

Resolution

1125 x 2436 pixels, 19.5:9 ratio (~458 ppi density)

Protection

Scratch-resistant glass, oleophobic coating

625 nits max brightness (advertised)
Dolby Vision
HDR10
Wide color gamut
3D Touch
True-tone
120Hz touch-sensing

PLATFORM

OS

iOS 11.1.1, upgradable to iOS 13.4

Chipset

Apple A11 Bionic (10 nm)

CPU

Hexa-core 2.39 GHz (2x Monsoon + 4x Mistral)

GPU

Apple GPU (three-core graphics)

MEMORY

Card slot

No

Internal

64GB 3GB RAM, 256GB 3GB RAM

NVMe

MAIN CAMERA

Dual

12 MP, f/1.8, 28mm (wide), 1/3", 1.22µm, dual pixel PDAF, OIS
12 MP, f/2.4, 52mm (telephoto), 1/3.4", 1.0µm, PDAF, OIS, 2x optical zoom

Features

Quad-LED dual-tone flash, HDR (photo/panorama), panorama, HDR

Video

4K@24/30/60fps, 1080p@30/60/120/240fps

SELFIE CAMERA

Dual

7 MP, f/2.2, 32mm (standard)
SL 3D, (depth/biometrics sensor)

Features

HDR

Video

1080p@30fps

SOUND

Loudspeaker

Yes, with stereo speakers

3.5mm jack

No

COMMS

WLAN

Wi-Fi 802.11 a/b/g/n/ac, dual-band, hotspot

Bluetooth

5.0, A2DP, LE

GPS

Yes, with A-GPS, GLONASS, GALILEO, QZSS

NFC

Yes

Radio

No

USB

2.0, proprietary reversible connector

FEATURES

Sensors

Face ID, accelerometer, gyro, proximity, compass, barometer

Siri natural language commands and dictation

BATTERY

Non-removable Li-Ion 2716 mAh battery (10.35 Wh)

Charging

Fast charging 15W, 50% in 30 min (advertised)
USB Power Delivery 2.0
Qi wireless charging

MISC

Colors

Space Gray, Silver

Models

A1865, A1901, A1902, A1903

SAR

1.09 W/kg (head)     1.17 W/kg (body)

TESTS

Performance

AnTuTu: 233100 (v7)
GeekBench: 10215 (v4.4)
GFXBench: 28fps (ES 3.1 onscreen)

Display

Contrast ratio: Infinity (nominal), 5.013 (sunlight)

Camera

Photo / Video

Loudspeaker

Voice 68dB / Noise 74dB / Ring 76dB

Audio quality
